Smart Motion Lighting. Effortless Control.
Upgrade your EU home with the RZ022 Occupancy Sensor Switch for automatic light and fan control. It detects motion to save energy and add hands-free convenience to any room.
FEATURES
- Automatically turns lights or fans on when motion is detected and off when the space is vacant.
- Advanced Passive Infrared (PIR) sensor technology for reliable human motion detection.
- Four distinct operating modes: Occupancy (auto on/off), Vacancy (manual on/auto off), Occupancy without light sensor (always activates with motion), and standard ON/OFF.
- Highly customizable: adjustable time delay (15 seconds to 30 minutes), light sensitivity (3 levels), and detection range.
- Designed for EU electrical systems (supports 220VAC loads).
- Easy setup with clear LED indicators for mode and settings.
SPECIFICATION
- Item Numbers: RZ022-5A / RZ022-10A
- Power Source: 110V~277VAC, 50/60Hz
- Detection Angle: ≤ 150°
- Detection Distance: 6-9 meters (at <27°C)
- Adjustable Time Delay: 15s, 1min (default), 3min, 5min, 15min, 30min
- Adjustable Light Sensor: 15Lux, 25Lux (default), 35Lux
- Max Load (RZ022-5A @220VAC): 1100W (Incandescent/Halogen), 350W (Fluorescent/Ballast/LED)
- Max Load (RZ022-10A @220VAC): 2200W (Incandescent/Halogen), 1000W (Fluorescent/Ballast/LED)
- Recommended Installation Height: 1.2m - 1.6m
- Working Temperature: -20°C to +40°C
- Working Humidity: < 93%RH
PRODUCT OVERVIEW
The RZ022 Occupancy Sensor Switch is a smart replacement for your standard light or fan switches, designed for modern EU households and offices. It uses advanced passive infrared (PIR) technology to detect heat emitted by motion, automatically controlling your connected devices.
This switch helps you save energy by turning lights or fans off when a room is unoccupied. You can tailor its operation with four modes: fully automatic Occupancy mode, energy-saving Vacancy mode (manual on, auto off), an Occupancy mode that ignores ambient light levels, or a simple manual ON/OFF function. Adjust settings like time delay before turn-off, and sensitivity to ambient light easily using the buttons on the switch face. Installation is straightforward, making it an easy upgrade for enhanced convenience and efficiency.
