Smart AC Control. Effortless Energy Savings.
Meet the RZ050, your smart solution to cut AC energy waste. This motion sensor controller automatically turns off your AC when rooms are empty, saving you money and ensuring comfort.
FEATURES
- Automatically powers off your air conditioner when a room is vacant, potentially cutting energy bills by 20-50%.
- Learns your existing AC remote's "Power OFF" command for wide compatibility with most split AC units.
- Wireless and battery-powered for simple DIY installation without any wiring.
- Intelligent Night Mode: Detects low light (‹1Lux) to prevent accidental shut-offs while you sleep.
- Customizable time delay settings: 15min, 30min, 1h (default), or 2h.
- Optional door/window sensor compatibility (RZ050-DS series) to further enhance energy savings.
- Low battery indicator and a motion detection light that can be toggled on/off.
SPECIFICATION
- Product Name: Air Conditioner Motion Sensor Controller RZ050.
- Power Source: 2x AAA batteries (2.5V-3.5VDC).
- Motion Detecting Range: 6-9 meters maximum.
- IR Transmitting Range: Less than 10 meters.
- IR Transmitting Direction: 30 degrees.
- Mounting: Screwing or sticking on the wall.
- Dimensions: 45 x 70 x 64 mm.
- Operating Environment: Indoor use only, 0~40°C, relative humidity up to 90%.
- Key Feature: Learns AC remote's "OFF" signal; does not turn AC "ON".
PRODUCT OVERVIEW
The RZ050 Air Conditioner Motion Sensor Controller is a smart device designed to help you reduce energy consumption from your split air conditioning units. It works by detecting motion in a room; if no movement is detected for a preset period (e.g., 15 minutes to 2 hours), it automatically sends an "OFF" signal to your AC, just like your AC's remote control would. This prevents your AC from cooling an empty room, leading to significant energy savings.
Installation is straightforward: it's wireless and battery-operated, so you can simply stick it or screw it onto a wall. The RZ050 is ideal for homes, offices, hotels, and B&Bs. It even features an intelligent night mode to ensure your AC doesn't turn off unexpectedly while you're sleeping, and a pet-friendly option to switch to a higher temperature instead of completely off. For enhanced savings, it can be paired with optional door/window sensors (RZ050-DS series) that will turn off the AC if a door or window is left open.
Quick AC Compatibility Test
RZ050
|
RZ050-DP
|
RZ050-DS
|
|
|---|---|---|---|
| Auto AC Control Modes | Turn AC OFF |
|
Turn AC OFF |
| Window/Door Sensor Compatible | No | No |
|
| Power Supply | Battery Only |
|
USB Only * |
Note : USB Power adaptor not included in the package, purchase here.
